Flame Sensor Infrared Receiver Ignition Source Detection Module

Original price was: ₹99.00.Current price is: ₹79.00.
slide 1
slide 1
slide 1
Image Slide 2
Image Slide 2
Image Slide 2
previous arrow
next arrow

Get Extra 5% off (up to ₹100) with UPI/Debit Card! The discounted price is: 75.05 (Original price: 79.00)

22 people have this product in their cart right now!

Product Details
Available Offers

This Flame sensor infrared receiver ignition source detection module is Arduino compatible can use to detect flame or wavelength of the light source within 760nm~1100nm also useful for Lighter flame detection at a distance of 80cm. This detection angle is about 60 degrees, especially sensitive to the flame spectrum. Greater the flame, the farther the test distance. The flame sensor detects…

In stock

Description

This Flame sensor infrared receiver ignition source detection module is Arduino compatible can use to detect flame or wavelength of the light source within 760nm~1100nm also useful for Lighter flame detection at a distance of 80cm. This detection angle is about 60 degrees, especially sensitive to the flame spectrum. Greater the flame, the farther the test distance.

The flame sensor detects a flame or the light of 760 ~ 1100nm wavelength, the lighter flame test distance 31.5in, for the larger flame, the further the distance test will be Infrared Flame Sensor produces the one-channel output signal at the D0 terminal for further processing like an alarm system or any switching system. The sensitivity is adjustable with the help of a blue potentiometer given on the board.

  • The flame detection sensor module
  • Fit for Arduino
  • Adjustable Accuracy
  • The detection angle is about 60 degrees, especially sensitive to the flame spectrum

Technical Details

  • Operating Voltage (VDC) : 3.3 ~ 5
  • Output Channel : 1
  • Mounting Hole(mm) : 3

Physical Attributes

  • Length × Width (mm) : 32 × 14
  • Weight (gm) : 3

Additional Details

  • Indicator light: a green one for the switch, a red one for power.
  • Built in a potentiometer for sensitivity control.
  • Onboard signal output indication, output effective signal is high, at the same time the indicator light up, the output signal can directly connect to microcontroller IO.
  • Can detect fire or wavelength in 760 ~ 1100 nm nano within the scope of the light source.
  • Detection angle about 60 degrees, the flame spectrum especially sensitive.
  • The flame of the most sensitive sensors flame, the regular light is also a response, generally used for fire alarm purposes.

Package Includes

  • 1 x Flame Sensor infrared Receiver Ignition source detection module

Additional information

Weight 0.2 kg
Dimensions 5 × 5 × 5 cm
